155Mb/S 120km CWDM SFP Transceivers Duplex LC 1270nm 1610nm SM DDM
제품 상세 정보:
| 원래 장소: | 중국 |
| 브랜드 이름: | NuFiber |
| 인증: | CE FCC Rohs |
| 모델 번호: | CWDM-SFP-FE-LX120-1270 |
결제 및 배송 조건:
| 최소 주문 수량: | 1개 부분 |
|---|---|
| 포장 세부 사항: | 10 PC / 플라스틱 백, 500 PC / 통 |
| 배달 시간: | 1-3 작업 일수 이내에 |
| 지불 조건: | L/C (신용장), 전신환, 웨스턴 유니온, 신용 카드 |
| 공급 능력: | 달 당 100,000 PC |
|
상세 정보 |
|||
| 상품 이름: | 155Mbps SFP 송수신기 | 사고 방식: | 1270~1610nm |
|---|---|---|---|
| 거리: | 120km | 연결기: | LC |
| 패키징: | CWDM SFP | 섬유형: | 두 부분으로 된 LC SM |
| 전원 공급기: | 3.3V | 작동 온도: | 0-70℃ |
| 제조사: | 예 | 적합합니다: | 시스코 화웨이 HP 쥬니퍼 기타 등등... |
| 보증: | 3년 | ||
| 하이 라이트: | 155Mb/S 120 킬로미터 CWDM SFP 송수신기,CWDM SFP 송수신기 이중 통신 LC 1270nm,155Mb/S 120 킬로미터 sm 스프피 모듈 |
||
제품 설명
155Mb/s 120km CWDM SFP Transceiver Duplex LC 1270nm ~ 1610nm SM DDM
Description
NuFiber’s CWDM-SFP-FE-LX120-XX Transceiver is a high performance, cost effective module which have a duplex LC optics interface. Standard AC coupled CML for high speed signal and LVTTL control and monitor signals. The receiver section uses a PIN receiver and the transmitter uses a 1270nm ~ 1610nm CWDM DFB laser, up to 29dB link budge ensure this module SONET OC-3/SDH STM-1 120km application.
Features
- Up to 155Mb/s Data Links
- Hot-Pluggable
- Duplex LC connector
- Up to 120km on 9/125μm SMF
- 1270nm～1610nm CWDM DFB laser transmitter
- Single +3.3V Power Supply
- Monitoring Interface Compliant with SFF-8472
- Maximum Power <1W
- Industrial /Extended/ Commercial operating temperature range: -40°C to 85°C/-5°C to 85°C/-0°C to 70°C Version available
- RoHS compliant and Lead Free
Applications
- SONET OC-3/SDH STM-1
- Fast Ethernet
- Other Optical Links
Optical Parameters(TOP = -40 to 85°C, VCC = 3.135 to 3.465 Volts)
| Parameter | Symbol | Min. | Typical | Max. | Unit | Note |
| Transmitter Section: | ||||||
| Center Wavelength | λc | λ-6 | λ | λ+7.5 | nm | |
| Spectral Width | σ | 1 | nm | |||
| Optical Output Power | Pout | 0 | 5 | dBm | 1 | |
| Optical Rise/Fall Time | tr / tf | 500 | ps | 2 | ||
| Extinction Ratio | ER | 10 | dB | |||
| Generated Jitter (peak to peak) | JTXp-p | 0.07 | UI | 3 | ||
| Generated Jitter (rms) | JTXrms | 0.07 | UI | 3 | ||
| Eye Mask for Optical Output | Compliant with G.957(class 1 laser safety) | |||||
| Receiver Section: | ||||||
| Optical Input Wavelength | λc | 1260 | 1620 | nm | ||
| Receiver Overload | Pol | -8 | dBm | 4 | ||
| RX Sensitivity | Sen | -34 | dBm | 4 | ||
| RX_LOS Assert | LOS A | -47 | dBm | |||
| RX_LOS De-assert | LOS D | -37 | dBm | |||
| RX_LOS Hysteresis | LOS H | 0.5 | dB | |||
| General Specifications: | ||||||
| Data Rate | BR | 155 | Mb/s | |||
| Bit Error Rate | BER | 10-12 | ||||
| Max. Supported Link Length on 9/125μm SMF@155Mb/s | LMAX | 80 | km | |||
| Total System Budget | LB | 29 | dB | |||
Ordering Information
| Dual Fiber SFP Transceiver | |
| Part Number | Product Description |
| 155Mbp/s SFP Transceiver | |
| FE-SX-MM850 | 155Mbps, 850nm MM 2km Dual LC, DDM 0°C~+70°C |
| FE-SX-MM1310 | 155Mbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C |
| FE-LX20-SM1310 | 155Mbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C |
| FE-LX40-SM1310 | 155Mbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C |
| FE-LX80-SM1550 | 155Mbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C |
| FE-LX120-SM1550 | 155Mbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C |
| 1.25Gbps SFP Transceiver | |
| GE-SX-MM850 | 1.25Gbps, 850nm MM 500m Dual LC, DDM 0°C~+70°C |
| GE-SX-MM1310 | 1.25gbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C |
| GE-LX20-SM1310 | 1.25Gbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C |
| GE-LX40-SM1310 | 1.25Gbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C |
| GE-LX60-SM1550 | 1.25Gbps, 1550nm SM 60km Dual LC, DDM 0°C~+70°C |
| GE-LX80-SM1550 | 1.25Gbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C |
| GE-LX120-SM1550 | 1.25Gbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C |
| 10Gbps SFP Transceiver | |
| SFP+-10GB-SR | 10G SFP+ SR Multi mode dual fiber LC 850nm 300M |
| SFP+-10GB-LRM | 10G SFP+ LRM Multi mode dual fiber LC 1310nm 220M |
| SFP+-10GB-LR | 10G SFP+ LR Single mode dual fiber LC 1310nm 20km |
| SFP+-10GB-ERM | 10G SFP+ER Single mode dual fiber LC 1310nm 40km |
| SFP+-10GB-ER | 10G SFP+ER Single mode dual fiber LC 1550nm 40km |
| SFP+-10GB-ZR | 10G SFP+ZR Single mode dual fiber LC 1550nm 80km |
| SFP+10G40-CWDM | 1470 ~1610nm CWDM SFP+ 40km |
| SFP+10G80-CWDM | 1470~1570nm CWDM SFP+ 80km |
| SFP+10G80-CWDM | 1590~1610nm CWDM SFP+ 80km |
| SFP+10G40-DWDM | DWDM SFP+ 40km |
| SFP+10G80-DWDM | DWDM SFP+ 80km |
| XFP Transceiver | |
| XFP-10G-SR | 10G XFP SR Multi mode dual fiber LC 850nm 300M |
| XFP-10G-LRM | 10G XFP LRM Single mode dual fiber LC 1310nm 10kM |
| XFP-10G-LR | 10G XFP LR Single mode dual fiber LC 1310nm 20km |
| XFP-10G-ER | 10G XFP ER Single mode dual fiber LC 1550nm 40km |
| XFP-10G-ZR | 10G XFP ZR Single mode dual fiber LC 1550nm 80km |
| CWDM DWDM Transceiver | |
| XFP-CWDM-40xx | 1470 ~1610nm CWDM XFP 40km |
| XFP-CWDM-80xx | 1470~1570nm CWDM XFP 80km |
| XFP-CWDM-80xx | 1590~1610nm CWDM XFP 80km |
| XFP-DWDM-40xx | DWDM XFP 40km |
| XFP-DWDM-80xx | DWDM XFP 80km |
| XFP-DWDM-100xx | DWDM XFP100km |
