80 킬로미터 1.25G CWDM SFP 모듈 송수신기 1270nm-1610nm 두 부분으로 된 LC SM

80 킬로미터 1.25G CWDM SFP 모듈 송수신기 1270nm-1610nm 두 부분으로 된 LC SM

제품 상세 정보:

원래 장소: 중국
브랜드 이름: NuFiber
인증: CE FCC Rohs
모델 번호: CWDM-SFP-GE80-1270

결제 및 배송 조건:

최소 주문 수량: 1개 부분
포장 세부 사항: 10 PC / 플라스틱 백, 500 PC / 통
배달 시간: 1-3 작업 일수 이내에
지불 조건: L/C (신용장), 전신환, 웨스턴 유니온, 신용 카드
공급 능력: 달 당 100,000 PC
최고의 가격 접촉

상세 정보

자료 비율: 1.25Gb/s 사고 방식: 1270~1610nm
거리: 80km 연결기: LC
패키징: CWDM SFP 섬유형: 두 부분으로 된 LC SM
전원 공급기: 3.3V 작동 온도: 0-70℃
제조사: 적합합니다: 시스코 화웨이 HP 쥬니퍼 기타 등등...
보증: 3년
하이 라이트:

1.25G CWDM SFP Module

,

80km CWDM SFP Module

,

1610nm sm 스프피 모듈

제품 설명

1.25Gb/s 80km CWDM SFP Transceiver Duplex LC 1270nm ~ 1610nm SM DDM

Description

The Nufiber’s CWDM-SFP-GE80-XX series single mode transceiver is small form factor pluggable module for duplex optical data communications such as Gigabit Ethernet 1000BASE-ZX and Fiber Channel 1x SM-LC-L FC-PI. It is with the SFP 20-pin connector to allow hot plug capability. This module is designed for single mode fiber and operates at a nominal wavelength of CWDM wavelength. There are eighteen center wavelengths available from 1270nm to 1610nm, with each step 20nm.

The transmitter section uses a multiple quantum well CWDM DFB laser and is a class 1 laser compliant according to International Safety Standard IEC-60825. The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC. The TSPL1G80D-xx series are designed to be compliant with SFF-8472.

Features

  • Data-rate of 1.25Gbps operation
  • 18-Wavelength CWDM DFB LD Transmitter from 1270nm to 1610nm, with Step 20nm
  • Compliant with SFP MSA and SFF-8472
  • Compatible with SONET OC-24-LR-1
  • Compatible with RoHS
  • +3.3V single power supply
  • Hot-Pluggable SFP Footprint Duplex LC
  • Operating case temperature
  • Standard : 0°C to +70°C
  • Extended: -20°C to +85°C
  • Industrial: -40°C to +85°C

Applications

  • Gigabit Ethernet
  • Fiber Channel Switch Infrastructure
  • Router/Server interface
  • Other optical transmission systems



Optical Parameters(TOP = -40 to 85°C, VCC = 3.135 to 3.465 Volts)


Parameter Symbol Min. Typical Max. Unit Note
Transmitter Section:
Center Wavelength λc λ-6 λ λ+7.5 nm
Spectral Width(-20dB) △λ     1 nm
Side Mode Suppression Ratio SMSR 30     dB
Optical Output Power Pout 0   +5 dBm 1
Optical Rise/Fall Time tr / tf     260 ps 2
Extinction Ratio ER 8.2     dB
Eye Mask for Optical Output Compliant with IEEE802.3z(class 1 laser safety)
Receiver Section:
Optical Input Wavelength λc 1260   1620 nm
Receiver Overload Pol -8     dBm 3
RX Sensitivity Sen     -24 dBm 3
RX_LOS Assert LOS A -40     dBm
RX_LOS De-assert LOS D     -25 dBm
RX_LOS Hysteresis LOS H 0.5     dB
General Specifications:
Data Rate BR   1.063/1.25   Gb/s
Bit Error Rate BER     10-12
Max. Supported Link Length on 9/125μm SMF@1.25Gb/s LMAX   80   km
Total System Budget LB 24     dB
























































Ordering Information

Dual Fiber SFP Transceiver
Part Number Product Description
155Mbp/s SFP Transceiver
FE-SX-MM850 155Mbps, 850nm MM 2km Dual LC, DDM 0°C~+70°C
FE-SX-MM1310 155Mbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C
FE-LX20-SM1310 155Mbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C
FE-LX40-SM1310 155Mbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C
FE-LX80-SM1550 155Mbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C
FE-LX120-SM1550 155Mbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C
1.25Gbps SFP Transceiver
GE-SX-MM850 1.25Gbps, 850nm MM 500m Dual LC, DDM 0°C~+70°C
GE-SX-MM1310 1.25gbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C
GE-LX20-SM1310 1.25Gbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C
GE-LX40-SM1310 1.25Gbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C
GE-LX60-SM1550 1.25Gbps, 1550nm SM 60km Dual LC, DDM 0°C~+70°C
GE-LX80-SM1550 1.25Gbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C
GE-LX120-SM1550 1.25Gbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C
10Gbps SFP Transceiver
SFP+-10GB-SR 10G SFP+ SR Multi mode dual fiber LC 850nm 300M
SFP+-10GB-LRM 10G SFP+ LRM Multi mode dual fiber LC 1310nm 220M
SFP+-10GB-LR 10G SFP+ LR Single mode dual fiber LC 1310nm 20km
SFP+-10GB-ERM 10G SFP+ER Single mode dual fiber LC 1310nm 40km
SFP+-10GB-ER 10G SFP+ER Single mode dual fiber LC 1550nm 40km
SFP+-10GB-ZR 10G SFP+ZR Single mode dual fiber LC 1550nm 80km
SFP+10G40-CWDM 1470 ~1610nm CWDM SFP+ 40km
SFP+10G80-CWDM 1470~1570nm CWDM SFP+ 80km
SFP+10G80-CWDM 1590~1610nm CWDM SFP+ 80km
SFP+10G40-DWDM DWDM SFP+ 40km
SFP+10G80-DWDM DWDM SFP+ 80km
XFP Transceiver
XFP-10G-SR 10G XFP SR Multi mode dual fiber LC 850nm 300M
XFP-10G-LRM 10G XFP LRM Single mode dual fiber LC 1310nm 10kM
XFP-10G-LR 10G XFP LR Single mode dual fiber LC 1310nm 20km
XFP-10G-ER 10G XFP ER Single mode dual fiber LC 1550nm 40km
XFP-10G-ZR 10G XFP ZR Single mode dual fiber LC 1550nm 80km
CWDM DWDM Transceiver
XFP-CWDM-40xx 1470 ~1610nm CWDM XFP 40km
XFP-CWDM-80xx 1470~1570nm CWDM XFP 80km
XFP-CWDM-80xx 1590~1610nm CWDM XFP 80km
XFP-DWDM-40xx DWDM XFP 40km
XFP-DWDM-80xx DWDM XFP 80km
XFP-DWDM-100xx DWDM XFP100km
