Single Fiber SM Xfp Fiber Transceiver 10Gb/S 40km Telecommunication Equipment
제품 상세 정보:
| 원래 장소: | 중국 |
| 브랜드 이름: | NuFiber |
| 인증: | CE FCC Rohs |
| 모델 번호: | XFP-10G-BX40-SM1270 |
결제 및 배송 조건:
| 최소 주문 수량: | 1 쌍 |
|---|---|
| 포장 세부 사항: | 10 PC / 플라스틱 백, 500 PC / 통 |
| 배달 시간: | 1-3 작업 일수 이내에 |
| 지불 조건: | L/C (신용장), 전신환, 웨스턴 유니온, 신용 카드 |
| 공급 능력: | 달 당 10,000 PC |
|
상세 정보 |
|||
| 자료 비율: | 10Gb/s | 사고 방식: | 1270/1330nm |
|---|---|---|---|
| 거리: | 40km | 연결기: | LC |
| DDM: | 지원 | 섬유형: | 단일 파이버 SM |
| 전원 공급기: | 3.3V | 작동 온도: | 0~70C |
| 보증: | 3년 | 호환성: | 시스코, HP, 화웨이, 피니사... |
| 제조사: | 예 | ||
| 하이 라이트: | SM 엑스프피 파이버 송수신기 10Gb/S,Single 섬유 엑스프피 파이버 송수신기 40 킬로미터 |
||
제품 설명
10Gb/s XFP Transceiver XFP-10G-BX40-SM1270 singlefiber SM 40km LC DDM
Description
NuFiber’ XFP-BX40-SM1330/1270 Bi-directional 10Gb/s (XFP) transceivers are compliant with the current XFP Multi-Source Agreement (MSA) Specification. They comply with 10-Gigabit Ethernet 10GBASE-LR/LW per IEEE 802.3ae,SONET OC-192 /SDH and 10G Fibre Channel 1200-SM-LL-L. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA.
Features
- Supports 9.95Gb/s to 11.3Gb/s bit rates
- Hot-pluggable XFP footprint
- Single LC for Bi-directional Transmission
- Maximum link length of 40km
- Built-in 1270/1330 WDM
- Uncooled 1270nm or 1330nm CWDM DFB Laser
- Power dissipation <2W
- No Reference Clock required
- Built-in digital diagnostic functions
- Temperature range 0°C to 70°C
- Very low EMI and excellent ESD protection
- RoHS Compliant Part
Applications
- 10GBASE-LR/LW Ethernet
- SONET OC-192 /SDH
- 1200-SM-LL-L 10G Fibre Channel
Optical Parameters
| Parameter | Symbol | Min | Typ | Max | Unit | Ref. | |
| Transmitter | |||||||
| Operating Date Rate | BR | 9.95 | 11.3 | Gb/s | |||
| Bit Error Rate | BER | 10-12 | |||||
| Maximum Launch Power | PMAX | -1 | +3 | dBm | 1 | ||
| Optical Center Wavelength | XFP-BX40-SM1270 | λ | 1260 | 1270 | 1280 | nm | |
| XFP-BX40-SM1330 | 1320 | 1330 | 1340 | ||||
| Optical Extinction Ratio | ER | 3.5 | dB | ||||
| Spectral Width | Δλ | 1 | nm | ||||
| Sidemode Supression ratio | SSRmin | 30 | dB | ||||
| Rise/Fall Time (20%~80%) | Tr/Tf | 50 | ps | ||||
| Average Launch power of OFF Transmitter | POFF | -30 | dBm | ||||
| Tx Jitter | Txj | Compliant with each standard requirements | |||||
| Optical Eye Mask | IEEE802.3ae | 2 | |||||
| Receiver | |||||||
| Operating Date Rate | BR | 9.95 | 11.3 | Gb/s | |||
| Receiver Sensitivity | Sen | -16 | dBm | 2 | |||
| Maximum Input Power | PMAX | 0 | dBm | 2 | |||
| Optical Center Wavelength | XFP-BX40-SM1270 | λC | 1320 | 1330 | 1340 | nm | |
| XFP-BX40-SM1330 | 1260 | 1270 | 1280 | ||||
| Receiver Reflectance | Rrx | -27 | dB | ||||
| LOS De-Assert | LOSD | -17 | dBm | ||||
| LOS Assert | LOSA | -27 | dBm | ||||
| LOS Hysteresis | LOSH | 0.5 | 5 | dB | |||
Ordering information
| Dual Fiber SFP Transceiver | |
| Part Number | Product Description |
| 155Mbp/s SFP Transceiver | |
| FE-SX-MM850 | 155Mbps, 850nm MM 2km Dual LC, DDM 0°C~+70°C |
| FE-SX-MM1310 | 155Mbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C |
| FE-LX20-SM1310 | 155Mbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C |
| FE-LX40-SM1310 | 155Mbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C |
| FE-LX80-SM1550 | 155Mbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C |
| FE-LX120-SM1550 | 155Mbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C |
| 1.25Gbps SFP Transceiver | |
| GE-SX-MM850 | 1.25Gbps, 850nm MM 500m Dual LC, DDM 0°C~+70°C |
| GE-SX-MM1310 | 1.25gbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C |
| GE-LX20-SM1310 | 1.25Gbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C |
| GE-LX40-SM1310 | 1.25Gbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C |
| GE-LX60-SM1550 | 1.25Gbps, 1550nm SM 60km Dual LC, DDM 0°C~+70°C |
| GE-LX80-SM1550 | 1.25Gbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C |
| GE-LX120-SM1550 | 1.25Gbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C |
| 10Gbps SFP Transceiver | |
| SFP+-10GB-SR | 10G SFP+ SR Multi mode dual fiber LC 850nm 300M |
| SFP+-10GB-LRM | 10G SFP+ LRM Multi mode dual fiber LC 1310nm 220M |
| SFP+-10GB-LR | 10G SFP+ LR Single mode dual fiber LC 1310nm 20km |
| SFP+-10GB-ERM | 10G SFP+ER Single mode dual fiber LC 1310nm 40km |
| SFP+-10GB-ER | 10G SFP+ER Single mode dual fiber LC 1550nm 40km |
| SFP+-10GB-ZR | 10G SFP+ZR Single mode dual fiber LC 1550nm 80km |
| XFP Transceiver | |
| XFP-10G-SR | 10G XFP SR Multi mode dual fiber LC 850nm 300M |
| XFP-10G-LRM | 10G XFP LRM Single mode dual fiber LC 1310nm 10kM |
| XFP-10G-LR | 10G XFP LR Single mode dual fiber LC 1310nm 20km |
| XFP-10G-ER | 10G XFP ER Single mode dual fiber LC 1550nm 40km |
| XFP-10G-ZR | 10G XFP ZR Single mode dual fiber LC 1550nm 80km |
