CE 3 킬로미터 1.25G SFP 송수신기, 1310nm LC 스프피 모듈 단일모드

CE 3 킬로미터 1.25G SFP 송수신기, 1310nm LC 스프피 모듈 단일모드

제품 상세 정보:

원래 장소: 중국
브랜드 이름: NuFiber
인증: CE FCC
모델 번호: GE-BX03-SM1310/1550

결제 및 배송 조건:

최소 주문 수량: 1 쌍
포장 세부 사항: 10 PC / 플라스틱 백, 200 PC / 통
배달 시간: 1-3 일 일
지불 조건: L/C (신용장), 전신환, 웨스턴 유니온
공급 능력: 달 당 100,000 PC
최고의 가격 접촉

상세 정보

속도: 1.25Gb/s 사고 방식: 1310nm/1550nm
거리: 3km 연결기: LC
DDM: 지원 섬유형: 단일모드 단일 파이버
전원 공급기: 3.3V 호환성: 시스코, 화웨이, HP...
작동 온도: 0~70C 보증: 3년
하이 라이트:

CE 3 킬로미터 1.25G SFP 송수신기

,

CE LC 스프피 모듈 단일 Mode

,

1.25G SFP 송수신기 단일모드

제품 설명

1.25Gb/s SFP Transceiver single fiber singlemode 3km 1310nm LC DDM

Description

NuFiber’s GE-BX03-SM1310/1550 Transceivers are a high performance, cost effective module which have a single LC optics interface. They are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) and Digital diagnostics functions are available via the 2-wire serial bus specified in SFF-8472. The receiver section uses a PIN receiver and the transmitter uses a 1310 nm FP laser, up to 14dB link budge ensure this module 1000Base-LX Ethernet 3km application.



Features

  • Up to 1.25Gb/s Data Links
  • Hot-Pluggable
  • Single LC connector
  • Up to 3 km on 9/125μm SMF
  • 1310nm FP laser transmitter
  • 1550nm PIN photo-detector
  • Single +3.3V Power Supply
  • Monitoring Interface Compliant with SFF-8472
  • Maximum Power <1W
  • Industrial /Extended/ Commercial Version available:
  • operating temperature range:
  • Industrial Grade:-40°C to 85°C
  • Extended grade:-5°C to 85°C
  • Commercial grade:-0°C to 70°C
  • RoHS compliant and Lead Free



Applications

  • 1000Base-LX Ethernet
  • Metro/Access Networks
  • 1×Fiber Channel
  • Other Optical Links



Optical Parameters(TOP = -40 to 85°C, VCC = 3.135 to 3.465 Volts)



Parameter Symbol Min. Typical Max. Unit Note
Transmitter Section:
Center Wavelength λc 1270 1310 1600 nm
Spectral Width(RMS) σRMS     4 nm
Optical Output Power Pout -9   -3 dBm 1
Extinction Ratio ER 9     dB
Optical Rise/Fall Time tr / tf     260 ps 2
Relative Intensity Noise RIN     -120 dB/Hz
Total Jitter Contribution TX Δ TJ     0.284 UI 3
Eye Mask for Optical Output Compliant with IEEE802.3 z (class 1 laser safety)
Receiver Section:
Optical Input Wavelength λc 1530 1550 1570 nm
Receiver Overload Pol -3     dBm 4
RX Sensitivity Sen     -24 dBm 4
RX_LOS Assert LOS A -40     dBm
RX_LOS De-assert LOS D     -25 dBm
RX_LOS Hysteresis LOS H 0.5     dB
General Specifications:
Data Rate BR   1.25   Gb/s
Bit Error Rate BER     10-12
Max. Supported Link Length on 9/125μm SMF@1.25Gb/s LMAX   20   km
Total System Budget LB 14     dB


























































Ordering information



BiDi SFP Transceiver
Part Number Product Description
155Mb/s SFP Transceiver
FE-BX20-SM1310/1550 155Mbps,BiDi 1310nm/1550nm SM 20km LC, DDM 0°C~+70°C
FE-BX40-SM1310/1550 155Mbps, BiDi 1310nm/1550nm SM 40km LC, DDM 0°C~+70°C
FE-BX80-SM1310/1550 155Mbps, BiDi 1310nm/1550nm SM 80km LC, DDM 0°C~+70°C
FE-BX100-SM1310/1550 155Mbps, BiDi 1310nm/1550nm SM 120km LC, DDM 0°C~+70°C
1.25Gbps SFP Transceiver
GE-BX10-SM1310/1550 1.25Gbps, BiDi 1310nm/1550nm SM 10km LC,DDM 0°C~+70°C
GE-BX20-SM1310/1550 1.25Gbps, BiDi 1310nm/1550nm SM 20km LC, DDM 0°C~+70°C
GE-BX40-SM1310/1550 1.25Gbps, BiDi 1310nm/1550nm SM 40km LC, DDM 0°C~+70°C
GE-BX60-SM1310/1550 1.25Gbps, BiDi 1310nm/1550nm SM 60km LC, DDM 0°C~+70°C
GE-BX80-SM1310/1550 1.25Gbps, BiDi 1310nm/1550nm SM 80km LC, DDM 0°C~+70°C
GE-BX100-SM1310/1550 1.25Gbps, BiDi 1310nm/1550nm SM 120km LC, DDM 0°C~+70°C
10Gbps SFP+ Transceiver
SFP-10G-BX20-SM1330/1270 10Gbps, BiDi 1330nm/1270nm SM 20km LC,DDM 0°C~+70°C
SFP-10G-BX40-SM1330/1270 10Gbps, BiDi 1330nm/1270nm SM 40km LC,DDM 0°C~+70°C
SFP-10G-BX60-SM1330/1270 10Gbps, BiDi 1330nm/1270nm SM 60km LC,DDM 0°C~+70°C
SFP-10G-BX80-SM1490/1550 10Gbps, BiDi 1490nm/1550nm SM 80km LC,DDM 0°C~+70°C
XFP Transceiver
XFP-BX20-SM1330/1270 10Gbps, BiDi 1330nm/1270nm SM 20km LC,DDM 0°C~+70°C
XFP-BX40-SM1330/1270 10Gbps, BiDi 1330nm/1270nm SM 40km LC,DDM 0°C~+70°C
XFP-BX60-SM1330/1270 10Gbps, BiDi 1330nm/1270nm SM 60km LC,DDM 0°C~+70°C
